A single-arm street light is a type of outdoor lighting fixture characterized by a **single horizontal or angled support arm** extending from a vertical pole, holding one or more luminaires (light heads). This design offers a **sleek, minimalist structure** while providing efficient illumination for roads, sidewalks, parking lots, and public spaces.
Key Features
Simple Design
The single-arm configuration ensures easy installation, low maintenance, and a clean aesthetic suitable for urban and suburban environments.
01
Versatile Applications
Ideal for narrow to medium-width roads, pathways, residential areas, and commercial zones due to its focused light distribution.
02
Durability
Constructed from corrosion-resistant materials like galvanized steel or aluminum, ensuring longevity in harsh weather conditions.
03
Energy Efficiency
Often equipped with LED modules for bright, uniform lighting, reduced energy consumption, and lower carbon footprints.
04
Smart Compatibility
Can integrate with smart systems (e.g., motion sensors, dimming controls, or IoT networks) to enhance energy savings and adaptive lighting.
05
Advantages
Cost-effective installation and upkeep.
Minimal visual obstruction compared to bulkier multi-arm designs.
Customizable heights (typically 5–12 meters) and arm lengths to meet specific lighting requirements.
This practical and modern lighting solution balances functionality, sustainability, and aesthetic appeal, making it a popular choice for urban infrastructure projects worldwide.
Key Attributes
|
Industry-specific attributes |
|
|
Lamp Body Material |
Die-casting aluminum |
|
Application |
Square / wharf / stadium / parkade / theme / park / highway |
|
Light Source |
LED |
|
Warranty (Year) |
Five years |
|
Other attributes |
|
|
Lighting solutions service |
CAD |
|
Color Temperature (CCT) |
4000K-6000K |
|
IP Rating |
ip66 |
|
Place of Origin |
Jiangsu, China |
|
Base Type |
Floodlight |
|
Lamp Luminous Efficiency (lm/w) |
150 |
|
Color Rendering Index (Ra) |
>70 |
|
Support Dimmer |
yes |
|
Lifespan (hours) |
50000 |
|
Input Voltage (V) |
dc 220v |
|
Lamp Luminous Flux (lm) |
>30000 |
|
Beam Angle (°) |
90-360 |
|
Brand Name |
YUNTENG |
|
Model Number |
YTDB |
|
Working Temperature (℃) |
-30 to 50 |
Product Paramenters
|
Pole height |
6M |
7M |
8M |
9M |
10M |
11M |
12M |
|
Thickness (mm) |
3.0 |
3.0 |
3.25 |
3.5 |
3.5 |
3.75 |
4.0 |
|
Lamp |
60-120W |
60-120W |
100-150W |
100-150W |
120-180W |
120-180W |
150-240W |
|
Material |
Q235 / Q355 / Q460 / GR65 |
||||||
|
Shape |
Round / Polygon |
||||||
|
Advantage |
High-quality, special design, reliable lifting system, safety and explosion-proof, anti-collision |
||||||
|
Send us your specs (CAD drawings accepted) – We'll engineer the perfect solution! |
|||||||
LED Luminaire Testing Center / LED Lamp Testing Center
Our Advantures
1. Manufacturer or solution provider.
2. Precise welding, no leakage welding, no edge bite, smooth surface without impurities.
3. Powder spraying process, pure polyester plastic powder coating stability, strong adhesion, UV resistance. Film thickness more than 10um, strong adhesion.
4. Hot dip galvanizing technology, internal and external surfaces by 75 microns above the hot dip zinc coating anticorrosion treatment.
5. One-stop service for government projects: preliminary design, interim documents, quality control production schedule, engineer guidance for installation.
6. Outdoor steel products expert, strong wind resistance, corrosion resistance, life up to 50 years years.
Strategic Partners with Chenghong Commerce
3,800 customers from more than 70 countries in the past 19 years.
